Tekniske Specifikationer

Thermal Module

  • Uncooled Focal Plane Arrays (Uopvarmede Focal Plane Arrays)
  • Max. Resolution (Maks. Opløsning): 640 × 512
  • Frame Rate (Billedhastighed): 50 Hz
  • Pixel Interval (Pixel Interval): 12 μm
  • NETD: Mindre end 35 mK (25 °C, F#=1.0)
  • Lens (Focal Length) (Linse (Brændvidde)): 35 mm
  • Detection Range (Registreringsområde): 3.5 m
  • Field of View (H × V), Degrees / m @100m (Synsfelt (H × V), Grader / m @100m): 12.5° × 10.0°
  • Min. Focusing Distance (Min. Fokuseringsafstand): 3.5 m
  • Aperture (Blænde): F1.0
  • Magnification (Forstørrelse): 1x

Image Display

  • Display: 1024x768, 0.39 tommer, OLED
  • Palettes (Farvepaletter): Sort varm, hvid varm, rød varm, fusion
  • Brightness Adjustment (Justerbar lysstyrke): Ja

General

  • Protection level (Beskyttelsesniveau): IP67
  • Weight (Vægt): 375 g uden øjestykke og batterier
  • Dimension (Dimension): 155.7 mm × 67.1 mm × 59.0 mm
  • Working Temperature (Arbejdstemperatur): -20 °C til 55 °C (-4 °F til 131 °F)

System

  • Record Video (Optagelse af video): Ja (On-board video recording)
  • Capture Snapshot (Tag øjebliksbillede): Ja
  • Hotspot: Ja
  • Standby Mode (Standby-tilstand): Ja
  • Storage (Lagerplads): Built-in EMMC (16 GB)
  • PIP (Billede-i-billede): Ja
  • DPC (Digital Pixel Correction): Ja
  • Digital Zoom (Digital zoom): Ja
  • Hot Track: Ja
  • Distance Measurement (Afstandsmåling): Ja
  • Audio Recording (Lydoptagelse): Ja
  • Recoil-activation Recording (Optagelse aktiveret af rekyl): Ja
  • Power Supply (Strømforsyning): 5 VDC, 2 A (Type-C Power Supply)

Pakkens Indhold

  • Quick Start Guide
  • 2x Batteri: CR1235
  • Klud
  • USB-kabel
  • Taske
  • Umbraco nøgle



​​
