Sensor
640x480 @ 17 µm (NETD <25 mK)
Objective lens
F50/1.0
Magnification,
x2 – 16 (x8 zoom)
Field of view (HxV), degrees / m@100m
12.4x9.3 / 21.8x16.3
Detection range,
m1800
Sensor
Type - uncooled
Resolution,
pixels 640x480
Pixel pitch
µm 17
NETD
mK <25
Frame rate,
Hz 50
Optics
Objective lens
F50/1.0
Magnification,
x2 - 16
Field of view (HxV), degrees / m @ 100 m
12.4x9.3 / 21.8x16.3
Eye relief,
mm 50
Display
Type
AMOLED HD
Resolution,
pixels 1024x768
Range Performance
Detection range,
m1800
Laser Rangefinder
Safety class for laser equipment according to IEC 60825-1:2014
Reticle
Click value, H/V, mm at 100 m
21 / 21 (on minimum magnification)
Click range, H/V, mm at 100 m
4200 / 4200
Number of preloaded reticles
10+
Video Recorder
Video / photo resolution,
pixel 1024x768
Video / photo format
.mp4 / .jpg
Built-in memory,
GB 16
Wi-Fi
Wireless Protocol
Wi-Fi
Wireless Standard
802,11 b/g
Frequency, GHz
2.4GHz
Line-of-sight reception range,
m15
Environmental Characteristics
Degree of protection, IP code (IEC60529)
IPХ7
Operating temperature range,
°С-25 – +50
Connections and Compatibilities
Max. recoil power on rifled weapon (Eo),
Joules 6000
Shock resistance on the smooth-bore rifles,
caliber 12
Mounting brackets on weapon
Standard 30 mm rings
Power Supply
Output voltage, V
3.0 – 4.2
Battery type
Dual Li-Ion B-Pack Mini Power System: 2 A·h Changeable Battery (external) / 3.2 A·h Battery (internal)
Capacity,
mAh2000 (external) + 3200 (internal)
Operating time on battery pack (at t=22°C),
h * 5+
External power supply,
V 5 (Micro USB Type B)
Body material
Metal
Dimensions,
mm402x78x80
Weight,
kg 0.9
Trade Data
SKU (Model #)
76543
Status
discontinued
